OEM electronics manufacturers require reliable display components that can be integrated into different products, instruments, control panels and electronic assemblies. Alfa Electronic Components supplies a comprehensive range of 7 Segment LED Displays, Clock LED Displays, Dotmatrix Displays, Alphanumeric Segment Displays, Arrow LED Displays, LED Bar Graphs and LED Light Bars for integration into OEM electronic equipment.
Electronic equipment manufacturers require display components for communicating numerical values, measurements, time, characters, symbols, directions, levels and operating status.
The correct display depends on the type of product being developed and the information its user interface needs to communicate.
7 Segment LED Displays provide numerical indication for measurements, counts, temperatures, settings and other values.
Clock LED Displays can be incorporated into equipment requiring time and timer information.
Alphanumeric Segment Displays support applications requiring letters and numbers, while Dotmatrix Displays can be considered for characters, symbols and simple graphical information.
Arrow LED Displays provide directional indication, while LED Bar Graphs and LED Light Bars support level, range and visual status indication.
This broad selection allows OEM manufacturers to evaluate display components according to their PCB design, equipment dimensions, user interface and application requirements.
The 1 Digit 7 Segment Display is a numeric LED display designed to present numbers from 0 to 9 clearly in electronic instruments, digital meters,…
A Two Digit Seven Segment Display is a compact LED numeric display designed to present values from 00 to 99 in digital counters, timers, measuring…
A 3 Digit 7 Segment Display is an integrated numeric LED display designed to present values from 000 to 999 in digital meters, counters, timers,…
A 4 Digit 7 Segment Display is an integrated numeric LED display designed to present values from 0000 to 9999 in digital meters, counters, timers,…
A 5 Digit 7 Segment Display is an integrated numeric LED display designed to present values from 00000 to 99999 in counters, measuring instruments, weighing…
A 6 Digit 7 Segment Display is an integrated numeric LED display designed to present values from 000000 to 999999 in counters, totalisers, meters, weighing…
A Single Digit Bi Color Seven Segment Display is a dual-color numeric LED display designed to show one digit from 0 to 9 while supporting…
A Seven Segment Jumbo Display is a large-size numeric LED display designed for applications where numbers must be visible from a longer distance. It is…
A 14/16 Segment Alphanumeric Display is an LED character display designed to show numbers, alphabets and selected symbols more clearly than a standard seven segment…
A 5x7 Round Dot Matrix Display is an LED character display made with a 5-column by 7-row dot arrangement, designed to show alphabets, numbers, symbols…
A 5x7 Square Dot Matrix Display is an LED character display designed with a 5-column by 7-row matrix arrangement, using square LED dots to show…
A 5x7 Round Bi Colour Dot Matrix Display is a dual-colour LED matrix display designed to show alphabets, numbers, symbols, short messages and status indications…
An 8x8 Round Dot Matrix Display is an LED matrix display designed with an 8-column by 8-row round dot arrangement, suitable for displaying alphabets, numbers,…
An 8x8 Bi Color Dot Matrix Display is a dual-color LED matrix display designed with an 8-column by 8-row round dot arrangement. It is suitable…
A Single Color LED Bar Graph is a linear LED display used to show level, progress, status, signal strength, battery condition, audio level, process value…
A Multi Color LED Bar Graph is a linear LED display used to show level, progress, signal strength, battery condition, audio level, process value or…
A Light Bar – Square Series is a single color LED indicator display designed in a square body format for status indication, signal indication, panel…
A Light Bar – Rectangle Series is a rectangular LED indicator display used for status indication, signal indication, panel indication, equipment display and machine interface…
A Light Bar – Round Series is a circular LED indicator display used for status indication, signal indication, panel indication, equipment display and machine interface…
| OEM Application | Suitable Display Products |
| Numerical Measurement Equipment | 3 Digit, 4 Digit, 5 Digit, 6 Digit 7 Segment Led Display |
| Compact Numerical Equipment | 1 Digit, 2 Digit, 3 Digit 7 Segment Led Display |
| Electronic Controllers | 3 Digit 7 Segment Led Display, 4 Digit 7 Segment Led Display, Alphanumeric Segment Display |
| Digital Clocks & Timers | 4 Digit 7 Segment Clock Led Display, 6 Digit 7 Segment Clock Led Display |
| Electronic Counters | 4 Digit, 5 Digit, 6 Digit 7 Segment Led Display |
| Large Numerical Equipment | Jumbo 7 Segment Display |
| Letters & Numerical Information | Alphanumeric Segment Display |
| Character & Symbol Equipment | 5×7 Round Dotmatrix Display, 5×7 Square Dotmatrix Display, 5×8 Round Dotmatrix Display, 8×8 Round Dotmatrix Display |
| Bi-Colour Character / Symbol Display | 5×7 Round Bi Color Dotmatrix Display, 8×8 Bi Color Dotmatrix Display |
| Directional Equipment | Arrow LED display up-down, Directional LED arrow display |
| Level & Range Indication | Single Color LED Bar Graph, Multi Color LED Bar Graph |
| Visual Status Indication | Single Digit Bi Color, LED Light Bar Square Series, LED Light Bar Rectangle Series, LED Light Bar Round Series |
Seven Segment LED Displays provide a straightforward format for displaying measurements, counts, temperatures, settings, time and other numerical information.
Different electronic products require different numerical formats.
Alfa’s range extends from 1 Digit to 6 Digit 7 Segment LED Displays, giving OEM manufacturers multiple configurations to evaluate according to their product requirements.
OEM equipment is not limited to numerical information.
Alphanumeric Segment Displays and Dotmatrix Displays can support applications requiring letters, characters and symbols.
4 Digit and 6 Digit 7 Segment Clock Led Displays can be considered for electronic products incorporating clocks, timers or other time-based functions.
Arrow LED display up-down and Directional LED arrow display can support OEM products requiring dedicated visual direction indication.
Single Color LED Bar Graph and Multi Color LED Bar Graph provide display options for electronic equipment requiring a visual representation of levels or changing ranges.
Display selection should begin with the information the product needs to communicate and then consider the mechanical and electronic requirements of the equipment.
Determine what needs to appear on the equipment interface:
Numerical values → Seven Segment LED Displays
Time information → Clock LED Displays
Letters and numbers → Alphanumeric Segment Display
Characters and symbols → Dotmatrix Displays
Directional information → Arrow LED Displays
Levels and ranges → LED Bar Graphs
Visual equipment status → LED Light Bars / Single Digit Bi Color
For numerical applications, determine the maximum number of positions required.
Single or compact values → 1 Digit / 2 Digit 7 Segment Led Display
Measurement and controller values → 3 Digit / 4 Digit 7 Segment Led Display
Extended numerical values → 5 Digit / 6 Digit 7 Segment Led Display
Character height should correspond with the normal viewing distance of the finished equipment.
A compact handheld or panel-mounted instrument will have different requirements from equipment designed to be read from several metres away.
For applications requiring larger numerical characters, the Jumbo 7 Segment Display can be considered.
Display colour should be selected according to the product interface, required contrast, visual hierarchy and available product configuration.
Bi-colour and multi-colour display products can be considered where colour differentiation forms part of the user interface.
Before finalising a display, OEM manufacturers should consider:
Overall display dimensions
Character height
Number of digits
Decimal-point requirements
Pin configuration
PCB footprint
Available PCB space
Mounting arrangement
Driver circuit compatibility
Viewing angle
Front-panel opening
Equipment enclosure dimensions
Required display orientation
These factors help ensure that the selected display fits both the electrical and mechanical design of the finished product.
During product development, OEM manufacturers should evaluate the display alongside the PCB, enclosure and interface design.
Sharing drawings, dimensions, required display format or an existing sample can help identify a suitable display configuration for the application.
Standard display products may not always match the layout required by a new electronic product.
An OEM manufacturer may require several display elements within the same interface, such as:
Multiple Seven Segment digits
Numerical and character displays
Numerical display with status indicators
Clock and indicator combinations
Dotmatrix and numerical combinations
Bar Graph and numerical displays
Directional arrows
Bi-colour indicators
Application-specific display arrangements
Depending on the requirement, Alfa Electronic Components can discuss the application and help identify suitable standard components or possible custom display configurations.
Multiple Seven Segment digits
Numerical and character displays
Numerical display with status indicators
Clock and indicator combinations
Dotmatrix and numerical combinations
Bar Graph and numerical displays
Directional arrows
Bi-colour indicators
Application-specific display arrangements
To help identify an appropriate LED display for a new or existing electronic product, manufacturers can share available technical and application information such as:
Application / Equipment Type
Required Display Type
Number of Digits
Required Character Height
Display Dimensions
Display Colour
Common Anode / Common Cathode Requirement, where applicable
Decimal-Point Requirement
Pin Configuration
PCB Layout or Available PCB Space
Required Viewing Distance
Existing Display Part Number, if replacing a display
Existing Sample or Photograph
Technical Drawing, if available
Required Quantity
Providing more application information can make it easier to evaluate an appropriate display option.
Alfa offers 1 Digit through 6 Digit 7 Segment Led Displays, 4 Digit and 6 Digit Clock Led Displays, Jumbo 7 Segment Display, Alphanumeric Segment Display, Dotmatrix Displays, Arrow LED Displays, LED Bar Graphs, LED Light Bars and Single Digit Bi Color for different electronic applications.
The appropriate display depends on the maximum numerical value, number of digits, character size, viewing distance, PCB design and information being displayed. Alfa offers 1 Digit through 6 Digit 7 Segment Led Display configurations for different numerical requirements.
Yes. Alfa Electronic Components supplies LED display components that can be considered for integration into OEM electronic products, instruments, controllers, panels and other electronic equipment.
LED display selection should be based on the product’s electrical and mechanical requirements, including display dimensions, pin configuration, PCB footprint and driver-circuit design. Relevant technical details should be reviewed before finalising the component.
The Alphanumeric Segment Display can be considered for applications requiring both letters and numbers. Dotmatrix displays can also support character and symbol information depending on the application.
Alfa’s 5×7, 5×8 and 8×8 Dotmatrix Displays can be considered for applications requiring characters, symbols or simple graphical information.
Yes. Alfa offers 4 Digit 7 Segment Clock Led Display and 6 Digit 7 Segment Clock Led Display for time-based electronic applications.
Yes. Arrow LED display up-down and Directional LED arrow display can be considered for equipment requiring directional indication.
Yes. Single Color LED Bar Graph and Multi Color LED Bar Graph can be considered where equipment requires visual representation of a level, range or changing parameter.
Application-specific display requirements can be discussed according to the required layout, dimensions, information type and technical specifications. Drawings, samples, photographs or application details can help in evaluating suitable standard components or possible custom configurations.
Useful information includes the equipment application, display type, number of digits, character height, dimensions, colour, pin configuration, PCB requirements and required quantity. An existing sample, photograph or technical drawing can also be useful when available.
If you are looking for a replacement or equivalent display, sharing the existing part number, photographs, dimensions, pin details or other available technical information can help in evaluating the requirement.
